Valcourt FP15 Waterloo High Efficiency Wood Burning Fireplace

The Waterloo’s smart air control system (patented) has been specifically designed to optimize combustion efficiency. Once the appliance is on and running, the combustion rate must be slowed down by manually closing the primary air damper. Then, when the system detects that the optimum combustion temperature has been reached, it automatically closes the second primary air damper and adjusts the secondary air control. Once the system is closed, it is possible to modulate the level of combustion by adjusting the auxiliary air control.

• Firebox volume 4.28 cu. ft.
• Overall heat output rating of 16,900 BTU/hr to 43,000 BTU/hr, with a maximum heat output of 95,000 BTU/hr
• The Glass Air-Wash System provides a self-cleaning' capability
• Double Ceramic Glass Door with Cast Iron Frame
• Requires 8" Chimney & Venting (Click Here to View 8" Venting)

---

Components Required For Installation:

Panels

• Classic Moulded Refractory Brick Panels

Faceplate

• Black Crown Style Faceplate

---

Options

• Forced Air Kit (VA4460)
• 5" Fresh Air Intake Register with Airtight Damper (AC01349)
• 6" x 25' Insulated Flex Pipe for Forced Air Kit (AC01350)
